Product Installation Guide
Professional installation guidance to help you easily complete the installation of WPC products
DECKING Installation
Installation - Decking
Preparation
01. Sweep the floor
02. Flat ground
03. Keel spacing
Installation
01. Use a tape measure to measure the length and width of the installation area and mark the positions
02. Place the keels along the marked lines, ensuring that the direction of the keels is perpendicular to the direction of the decking installation
03. Use a power drill to pre-drill holes at the marked positions on the wood-plastic keels. Use a rubber mallet to tap the expansion screws into place, securing the keels
04. Pre-drill holes in the keels, then secure the start clips to the keels with screws. Install the start clips sequentially
05. Align the first decking with the start clips, ensuring the edges are neat
06. Use the clips to secure the decking sequentially, following the usage ratio of the two types of clips as shown in the diagram
07. Insert the clips into the decking and secure the clips to the keels with screws
08. Install the remaining deckings sequentially
